Schneider ATV630C13N4F Altivar Process ATV600 variable speed drive
Please contact me get more information
Email:
[email protected]VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
Main
Range of Product Altivar Process ATV600
Product or Component Type Variable speed drive
Product Specific Application Process and utilities
Device short name ATV630
Variant Standard version
Product destination Asynchronous motors
Synchronous motors
EMC filter Integrated 492.1 ft (150 m) IEC 61800-3 category C3
IP degree of protection IP00IEC 61800-5-1
IP00IEC 60529
IP21 with kit VW3A9704)IEC 61800-5-1
IP21 with kit VW3A9704)IEC 60529
[Us] rated supply voltage 380...480 V
Type of cooling Forced convection
Supply frequency 50...60 Hz - 5...5 %
[Us] rated supply voltage 380...480 V - 15...10 %
Motor power kW 132 kW normal duty)
110 kW heavy duty)
Maximum Horse Power Rating 200 hp normal duty
150 hp heavy duty
Line current 237 A 380 V normal duty)
213 A 480 V normal duty)
201 A 380 V heavy duty)
165 A 480 V heavy duty)
Prospective line Isc 50 kA
Apparent power 161.4 kVA 480 V normal duty)
121.8 kVA 480 V heavy duty)
Continuous output current 250 A 2.5 kHz normal duty
211 A 2.5 kHz heavy duty
Asynchronous motor control
profile
Constant torque standard
Optimized torque mode
Variable torque standard
Synchronous motor control profile Permanent magnet motor
Synchronous reluctance motor
Speed drive output frequency 0.1…500 Hz
Nominal switching frequency 2.5 kHz
