Schneider Electric Altistart 01 soft starter ATSU01N232LT
soft starter for asynchronous motor,Altistart U01, TeSys U, ATSU01,32A, 200 to 480V, 7.5 to 15kW
Please contact me get more information
Email:
[email protected]VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
Main
Range of Product Altistart U01 and TeSys U
Product or Component Type Soft starter
Product destination Asynchronous motors
Product Specific Application Simple machine
Device short name ATSU01
Phase 3 phase
[Us] rated supply voltage 200...480 V - 10...10 %
Motor power kW 15 kW, 3 phase 400 V
7.5 kW, 3 phase 230 V
Maximum Horse Power Rating 10 hp, 3 phase 230 V
20 hp, 3 phase 460 V
IcL starter rating 32 A
Utilisation category AC-53B EN/IEC 60947-4-2
Current consumption 100 mA
Type of start Start with voltage ramp
Power dissipation in W 2.5 W at full load and at end of starting
322.5 W in transient state
Please contact me get more information
Email:
[email protected]VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
Complementary
Assembly style With heat sink
Function Available Integrated bypass
Supply voltage limits 180…528 V
Supply frequency 50...60 Hz - 5...5 %
Network Frequency 47.5...63 Hz
Output voltage <= power supply voltage
[Uc] control circuit voltage 24 V DC +/- 10 %
Starting time Adjustable from 1 to 10 s
1 s / 50
10 s / 5
5 s / 10
Deceleration time symb Adjustable from 1 to 10 s
Starting torque 30...80 % of starting torque of motor connected directly on the line supply
Discrete input type Logic LI1, LI2, BOOST) stop, run and boost on start-up functions <= 8 mA 27 kOhm
Environment
Electromagnetic compatibility Conducted and radiated emissions level B CISPR 11
Conducted and radiated emissions level B IEC 60947-4-2
Damped oscillating waves level 3 IEC 61000-4-12
Electrostatic discharge level 3 IEC 61000-4-2
EMC immunity EN 50082-1
EMC immunity level B EN 50082-2
Harmonics level 3 IEC 1000-3-2
Harmonics level 3 IEC 1000-3-4
Immunity to electrical transients level 4 IEC 61000-4-4
Immunity to radiated radio-electrical interference level 3 IEC 61000-4-3
Voltage/current impulse level 3 IEC 61000-4-5
Conducted and radiated emissions level 3 IEC 61000-4-6
Immunity to conducted interference caused by radio-electrical fields level 4 IEC
