ABB AC 800M Communication interfaces CI873AK01
The CI873A is an AC 800M communication interface that connects to external Ethernet devices using the EtherNet/IP protocol. The TP867 Baseplate has two RJ45 Ethernet connectors, but only the CH1 connector that supports 100Mbps is used. The CI873 expansion unit contains the CEX-Bus logic, a communication unit, and a DC/DC converter that supplies the required voltage from +24 V supply through the CEX-Bus.
The CI873A module will only work with System 800xA 6.0.3.3, 6.1.1 and subsequent versions. The CI873A support 6 redundant pairs of CI873A from 5.1 FP4.
Please contact me get more information
Email:
[email protected]VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
General info
Article number 3BSE092695R1
Communication protocol EtherNet IP / DeviceNet
Master or slave Master
Transmission speed 10/100 Mbit/s
Line redundancy No
Module redundancy Yes
Hot Swap Yes
Used together with HI Controller Yes
Detailed data
Max units on CEX bus 12
Connector RJ-45 female (8-pin)
24 V consumption typ. typ 160 mA
Environment and certification
Temperature, Operating +5 to +55 °C (+41 to +131 °F)
Temperature, Storage -40 to +70 °C (-40 to +158 °F)
Altitude 2000 m according to IEC/EN 61131-2
Pollution degree Degree 2 according to IEC/EN 61131-2
Corrosion protection G3 compliant to ISA 71.04
Relative humidity 5 to 95 %, non-condensing
Protection class IP20 according to EN60529, IEC 529
CE- marking Yes
Electrical Safety UL 61010-1, UL 61010-2-201
Hazardous location UL 60079-15, cULus Class 1, Zone 2, AEx nA IIC T4, ExnA IIC T4Gc X
Marine certificates DNV-GL, (Pending: ABS, BV, LR)
RoHS compliance DIRECTIVE/2011/65/EU (EN 50581:2012)
WEEE compliance DIRECTIVE/2012/19/EU
Dimensions
Width 59 mm (2.3 in.)
Height 185 mm (7.3 in.)
Depth 127.5 mm (5.0 in.)
Weight (including base) 700 g (1.5 lbs)
