ENDRESS AND HAUSER LEVEL SENSOR CAPACITIVE PNP140MM ROD FTC260-AA4D1
Endress and Hauser FTC260 AA level transmitter liquid measuring method capacitive connection voltage 20 - 253V frequency connection voltage AC/DC housing polyester (thermoplastic) male thread gas conical (BSPT) thread 1 degree of protection (IP) IP65 insertion length transmitter 140
More models
FTC260-BA2J1
FTC260-AA4D1
FTC731-AA4D1
FTC730-AA4D1
Please contact me get more information
Email:
[email protected]VK/Whatsapp/Telegram:+8613667120925
Website: www.cwlyautomation.com
Related products
RN22 active barrier
RN42 active barrier
Degree of protection (IP):
IP65
Housing material:
Polyester (thermoplastic)
Connection:
External thread conical BSPT-R (ISO 7-1 / EN 10226-1)
Accuracy:
0 mm
Insertion length sensor:
140 mm
Frequency of connection voltage:
AC/DC
Measurement method:
Capacitive
External electronics required:
Article number:
14176352
Keywords:
Level sensor, Level sensor liquid, Level sensor, sensor, Sensor for level measurement, dust
Fire:
Endress and Hauser
Maximum medium temperature (continuous):
120 °C
Minimum medium temperature (continuous):
-40 °C
Maximum working pressure at 20 grC:
25 bar
Number of electrode(s):
N/A
Length of electrode(s):
0 m
Field of application
Minicap FTC260 is a simple and cost-effective rod probe for point level detection in bulk solids, particularly suited to applications involving aggressive media and heavy build-up. It is designed for point level detection of light bulk solids, e.g. grain products, flour, milk powder, animal feed, cement, chalk or gypsum.
For point level detection of light bulk solids, with a grain size up to max. 30mm and a dielectric constant εr ≥ 1.6.
Typical applications: Grain products, flour, milk powder, animal feed, cement, chalk or gypsum.
Process connection: Threads
Temperature: -40 to +80°C (-40 to +176°F)
Pressure: -1 to +25bar (-14.5 to +360psi)
Sensor length: 140mm (5.51")
International explosion protection certificates, overfill prevention WHG
