Pilz Safety relay 750104 PNOZ s4 24VDC 3 n/o 1 n/c
One PNOZ safety relay is used per safety function. PNOZsigma safety relay (standalone), inputs: 1/2-channel wiring with/without detection of shorts across contacts, manual/automatic start, outputs: 3 N/O, 1 N/C, 1 SC, UB 24 V DC, width: 22.5 mm, plug-in screw terminals, monitoring of E-STOP, safety gates, light guard.
Technical data
Electrical data
Supply voltage (V) 24 V
Type of supply voltage U1 DC
Power consumption DC 2.5 W3
Normally Open contacts, 1 Normally Closed, 1 Semiconductor
24 Vdc supply voltage
DIN rail mounting
Operating modes, single channel, automatic reset, dual channel
Screw terminals
Email:
[email protected]Tel: +86 13667121125 whatsapp/ vk/ telegram also available
Company: CW Green Tech
The Pilz PNOZ sigma series Safety Relay meets the requirements of EN 60947-5-1, EN 60204-1 and VDE 0113-1 and may be used in applications with E-Stop. The PNOZ s4 series from Pilz are safety relays for monitoring E-STOP pushbuttons, safety gates and light beam devices.
PILZ Safety relay Pilz 751104 - PNOZ s4 C 24VDC 3 n/o 1 n/c
PILZ PNOZ s4 48-240VAC/DC 3n/0 1n/c Safety relay750134
Pilz 750104 PNOZ s4 24VDC 3 n/o 1 n/c
Pilz 750134 PNOZ s4 48-240VACDC 3 n/o 1 n/c.
Pilz 751104 PNOZ s4 C 24VDC 3 n/o 1 n/C.
PILZ PNOZ s4 24VDC 3n/o 1n/c.
